1 wan port 2 lan ports 2.4G wifi Cat 4 best 4g wifi router

Name: 1 wan port 2 lan ports 2.4G wifi Cat 4 best 4g wifi router
Brand: Junhaoyue
Rating: 10 (2 reviews)

Item no.:	HY8625
Chipset:	MT7628DA, L716-EU-12
4g frequency:	FDD: B1/B2/B3/B4/B5/B7/B8/B28/B66; TDD: B38/B40; WCDMA: B1/B2/B5/B8
Price:	USD 25.00 - 35.00

Add to Basket

Product Description Performance Features and Material

Product Description

Description	1 wan port 2 lan ports 2.4G wifi Cat 4 best 4g wifi router
Item no.	HY8625
Chipset	MT7628DA, L716-EU-12
CPU Frequency	580MHz
Memory	64MB
Flash	16MB
WIFI	High-Power
LTE	DL 150Mbps; UL 50Mbps
Device Interfaces	1 x Nano SIM Card Slot
	2 x RJ45 10M/100M LAN Ethernet Port
	1 x RJ45 10M/100M WAN Ethernet Port
	1 x Reset Button
	1 x DC Port
	1 x Type-C Port
WIFI Antenna	2 x 5dBi External Antenna
LTE Antenna	2 x 5dBi External Antenna
Power Supply	DC 12V/1A, Type-C 5V/2A
4G Frequency	FDD: B1/B2/B3/B4/B5/B7/B8/B28/B66 TDD: B38/B40 WCDMA: B1/B2/B5/B8 Frequency can be customized
Wifi Standard	IEEE802.11b/g/n, (WiFi4) 11N:300Mbps, 2.4~2.4835GHz
Modulation Schemes	OFDM = BPSK,QPSK, 16-QAM, 64-QAM
Modulation Schemes	DSSS = DBPSK, DQPSK, CCK
Transfer Rate	HT20: up to 144 Mbps HT40: up to 300 Mbps
WAN Type	4G/3G/2G or Wired
4G/3G Features	Auto-APN
	Auto dial-up
	Roaming
	SMS(Send/Receive/Delete)
	USSD
	PIN Management
Wi-Fi	SSID, Broadcast and Hide Wi-Fi Name
	WEP, WPA-PSK, WPA2-PSK, WPA/WPA2,WPA3
	WiFi Frequency, Channel, Bandwidth
	MAC IP Address Blacklist and Whitelist
Firewall	NAT(DMZ, UPNP)
	telnet, ping, http
	Defense Dos Attacks
	User Define to Prevent Attacks
Management	User Access Restrictions
	URL Filter
	QOS speed limit
	System Log
	System Settings
	Traffic Statistics of Wireless and Ethernet Networks
	Ping or Traceroute to Check the Network Working Status
	Iperf Speed Test
	IPV4/IPV6
	Upgrade Firmware from Local
Operating Environment	Operating Temperature:Normal:0°C to +45°C; Operating Temperature:-20° C to +70° C Operating Humidity:5%~ 95% Storage Humidity:5%~ 95%
Dimension	Device: 31023041mm CTN size: 48.843.833.5 CM, 20pc/ctn G.W.: 11.72 KGS

Performance Features and Material

Advantages	Cat 4 LTE Speeds: The HY8625 router is equipped to handle Category 4 LTE speeds, ensuring fast and efficient mobile internet connections. 2.4G WiFi: Offers 2.4GHz WiFi for broader coverage and compatibility with a wide range of devices. 1 WAN and 2 LAN Ports: Provides a WAN port for internet connection and two LAN ports for wired networking, ideal for small networks. Advanced Chipset: Features the MT7628DA, L716-EU-12 chipset, known for stable performance and reliable data transfer. Robust Anti-Interference: Capable of maintaining a strong signal even in environments with multiple WiFi networks, ensuring minimal disruptions.
Product Description	The HY8625 is a high-performance 4G WiFi router designed for small and medium-sized enterprises looking for reliable and fast internet solutions. With Category 4 LTE capabilities, it offers swift mobile connectivity. The inclusion of 2.4GHz WiFi ensures broad coverage, and the 1 WAN port along with 2 LAN ports caters to various networking needs. Powered by the MT7628DA, L716-EU-12 chipset, this router delivers on stability and performance. Priced between USD 25.00 and 35.00, it's an affordable choice for businesses seeking to enhance their network infrastructure without compromise on quality.
Guidelines for use	Power Up: Connect the HY8625 to a power source and initiate the boot process. SIM Card Installation: Insert a compatible 4G SIM card into the router's SIM card slot to establish a mobile internet connection. Connect Devices: Connect your devices to the router's WiFi network or use the LAN ports for a wired connection. Network Management: Use the router's web interface to manage network settings, monitor data usage, and adjust configurations as needed.
How to Install	Router Positioning: Find an optimal location for the router with strong cellular signal strength and minimal physical obstructions. Power Connection: Connect the router to a power outlet using the provided power adapter. Initial Configuration: Access the router's web interface to configure the network settings, including the WiFi password and SIM card activation.
How to Set Up	Web Interface Access: Connect your computer to the router's network and navigate to the router's web interface. Network Configuration: Set up the WiFi network name (SSID) and password, and configure the internet access settings according to your service provider's instructions. Advanced Settings: Customize additional settings such as security protocols, parental controls, or VPN configurations to suit your preferences.
Usage Precautions	Environmental Protection: Keep the router in a dry and dust-free environment to prevent performance degradation and maintain longevity. Firmware Updates: Regularly check for and install firmware updates to ensure the router's security and optimal functionality. Antenna Alignment: If the router has external antennas, adjust them for the best signal reception and coverage. Secure Your Network: Protect your network with a strong password and enable encryption to prevent unauthorized access. Regular Monitoring: Monitor the router's performance regularly and address any connectivity issues promptly to ensure continuous and stable internet service.
