Wifi 6 optional 2.4g wifi 1 lan sim card wifi router 4g

Name: Wifi 6 optional 2.4g wifi 1 lan sim card wifi router 4g
Brand: Junhaoyue
Rating: 10 (2 reviews)

Model Number:	HY8805
CPU:	ASR 1803S
Power Supply:	DC 12V/1A or Type-C 5V/1A
Frequency:	FDD LTE: B1/B3/B5/B7/B8/B20/B28; TDD LTE: B38/B40/B41
Price:	USD11.00-USD15.00

Add to Basket

Product description Performance Features and Material

Product description

Description	Wifi 6 optional 2.4g wifi 1 lan sim card wifi router 4g
Item no.	HY8805
CPU	ASR 1803S
Power Supply	DC 12V/1A or Type-C 5V/1A
Power Consumption	Normal Operation Power <2W
Frequency	FDD LTE: B1/B3/B5/B7/B8/B20/B28 TDD LTE: B38/B40/B41 WCDMA: B1/B5/B8
Speed	LTE-FDD: Max 150Mbps(DL) Max 50Mbps(UL) LTE-TDD: Max 130Mbps(DL) Max 35Mbps(UL) WCDMA: Max 7.2Mbps(DL) Max 5.76Mbps(UL)
WIFI	802.11b/g/n, 2.4G (WiFi 6 optional)
LED Indicator	Power LEDx1 4G Link LEDx1 LAN LEDx1
Network Interface	1 RJ45 LAN, 10/100Mbps, auto MDI/MDIX
Antenna	24G/5DBi, 12.4G WiFi/5DBi, 1/Decoration
SIM card	Nano SIM card
eSIM	Optional
Reset	Press and hold for 5s to restore factory default
WiFi security	WPA/WPA2
Protocol	IEEE 802.11n; IEEE 802.11g; IEEE 802.11b
Operating Environment	Operating Temperature:Normal:0°C to +45°C; Operating Temperature:-20° C to +70° C Operating Humidity:5%~ 95% Storage Humidity:5%~ 95%
Dimension	Device: 22021545cm; 0.43Kg/pc; 40pcs/ctn; CTN size: 642458362mm; G.W.: 18.30Kg/ctn;

Performance Features and Material

Advantages	WiFi 6 Technology: Supports the latest WiFi 6 standards for enhanced wireless speeds and efficiency. Optional 2.4G WiFi: Provides the flexibility to use the 2.4GHz band for wider coverage or the 5GHz band for less interference. Single LAN Port: Offers a dedicated Ethernet port for a stable wired connection. SIM Card Slot: Enables the use of 4G LTE networks for internet access, ideal for areas without reliable broadband. Versatile Power Supply: Supports both DC 12V/1A and Type-C 5V/1A, allowing for power flexibility in various scenarios. Broad Frequency Support: Compatible with a wide range of FDD and TDD LTE bands for global roaming capabilities.
Product Description	The HY8805 is a compact and versatile 4G WiFi router that integrates WiFi 6 technology with the option to use 2.4G WiFi. It features a single LAN port for wired connections and a SIM card slot for 4G LTE connectivity. Powered by the ASR 1803S CPU, it ensures reliable performance. With support for a broad range of LTE frequencies, it's suitable for travel and global use. Priced affordably between USD 11.00 and 15.00, the HY8805 is an excellent choice for on-the-go internet solutions.
Guidelines for use	Power Connection: Connect the HY8805 to a power source using either the DC 12V/1A or Type-C 5V/1A input. SIM Card Installation: Insert a compatible 4G SIM card into the router's SIM card slot. Network Access: Configure the wireless network by connecting to the router's default WiFi or using the LAN port. Customization: Tailor the network settings to your preferences through the router's management interface.
How to Install	Router Positioning: Place the router in a location with strong cellular signal and clear line of sight for WiFi distribution. Power Source Attachment: Attach the appropriate power cable to the router and connect it to a power outlet or PoE switch. Network Configuration: Use a device connected to the router to access its configuration page and set up the network as needed.
How to Set Up	Access Management Interface: Connect your computer to the router and open a web browser to reach the management interface. Initial Setup: Follow the on-screen instructions to set up the WiFi network name (SSID), password, and other basic settings. Advanced Settings: For more advanced configurations, such as parental controls or VPN setup, delve into the router's advanced settings menu.
Usage Precautions	Environmental Considerations: Use the router in environments within its operational temperature range to prevent overheating or damage. Firmware Updates: Regularly check for and apply firmware updates to enhance functionality and security. Antenna Maintenance: If the router has external antennas, adjust them for optimal signal reception and keep them free from obstructions. Secure Your Network: Protect your network with a strong password and enable encryption to prevent unauthorized access. Regular Monitoring: Monitor the router's performance and address any issues promptly to ensure continuous connectivity.
