Description

Wifi 6 optional 2.4g wifi 1 lan sim card wifi router 4g

Item no.

HY8805

CPU

ASR 1803S

Power Supply

DC 12V/1A or Type-C 5V/1A

Power Consumption

Normal Operation Power <2W

Frequency

FDD LTE: B1/B3/B5/B7/B8/B20/B28

TDD LTE: B38/B40/B41

WCDMA: B1/B5/B8

Speed

LTE-FDD: Max 150Mbps(DL) Max 50Mbps(UL)

LTE-TDD: Max 130Mbps(DL) Max 35Mbps(UL)

WCDMA: Max 7.2Mbps(DL) Max 5.76Mbps(UL)

WIFI

802.11b/g/n, 2.4G (WiFi 6 optional)

LED Indicator

Power LEDx1

4G Link LEDx1

LAN LEDx1

Network Interface

1 RJ45 LAN, 10/100Mbps, auto MDI/MDIX

Antenna

2*4G/5DBi, 1*2.4G WiFi/5DBi, 1/Decoration

SIM card

Nano SIM card

eSIM

Optional

Reset

Press and hold for 5s to restore factory default

WiFi security

WPA/WPA2

Protocol

IEEE 802.11n; IEEE 802.11g; IEEE 802.11b

Operating Environment

Operating Temperature:Normal:0°C to +45°C;

Operating Temperature:-20° C to +70° C

Operating Humidity:5%~ 95%

Storage Humidity:5%~ 95%

Dimension

Device: 220*215*45cm; 0.43Kg/pc; 40pcs/ctn;

CTN size: 642*458*362mm; G.W.: 18.30Kg/ctn;
